CAMERA IP HDBW8231EP-Z
- Camera Dahua Wifi Lechange Imou DH-IPC-C26EP
- Tích hợp kết nối Wifi Không Dây.
- Độ phân giải 2Megapixel CMOS 1/2.7” (1080P).
- Tầm xa hồng ngoại 10m.
- Ống kính cố định 2.8mm, góc nhìn 84°.
- Tích hợp đèn flash và còi hú báo động.
- Đàm thoại hai chiều.
- Hỗ trợ khe cắm thẻ nhớ Micro SD, Max 128GB.
- Bảo hành chính hãng 24 tháng.
Danh mục : CAMERA DAHUA CAMERA IP
| Camera | |||||
| Image Sensor | 1/2.8” 2Megapixel progressive scan CMOS | ||||
| Effective Pixels | 1920(H)x1080(V) | ||||
| RAM/ROM | 1024MB/128MB | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | Auto/Manual, 1/3~1/100000s | ||||
| Minimum Illumination | 0.005Lux/F1.4 (Color,1/3s,30IRE)
0.03Lux/F1.4 (Color,1/30s,30IRE) 0Lux/F1.4(IR on) |
||||
| S/N Ratio | More than 50dB | ||||
| IR Distance | Distance up to 50m(164ft) | ||||
| IR On/Off Control | Auto/ Manual | ||||
| IR LEDs | 3 | ||||
| Lens | |||||
| Lens Type | Motorized /Auto Iris(HALL) | ||||
| Mount Type | Board-in | ||||
| Focal Length | 2.7~12mm motorized | ||||
| Max. Aperture | F1.4 | ||||
| Angle of View | H: 110 ˚~36 ˚ V:57 ˚ ~20 ˚ | ||||
| Optical Zoom | 4x | ||||
| Focus Control | Motorized | ||||
| Close Focus Distance | 0.5m(1.64ft) | ||||
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| W | 49m(162ft) | 20m(66ft) | 10m(33ft) | 5m(16ft) | |
| T | 125m(410ft) | 50m(164ft) | 25m(82ft) | 13m(43ft) |
| Pan/Tilt/Rotation | |||||
| Pan/Tilt/Rotation Range | Pan:0˚~355˚; Tilt:0˚~65˚; Rotation:0˚~355˚ | ||||
| Intelligence | |||||
| IVS | Tripwire, Intrusion, Object Abandoned/Missing | ||||
| Advanced Intelligent Functions | Face Detection, People Counting, Heat Map | ||||
| Video | |||||
| Compression | H.265+/H.265/H.264+/H.264 | ||||
| Streaming Capability | 3 Streams | ||||
| Resolution | 1080P(1920×1080)/ 1.3M(1280×960)/
720P(1280×720)/ D1(704×576/704×480) / VGA(640×480)/ CIF(352×288/342×240) |
||||
| Frame Rate | Main Stream: 1080P(1~50/60fps) | ||||
| Sub Stream: D1 (1 ~ 50/60fps) | |||||
| Third Stream: 1080P(1~50/60fps) | |||||
| Bit Rate Control | CBR/VBR | ||||
| Bit Rate | H.264: 24~ 10240Kbps
H.265: 14~ 6144Kbps |
||||
| Day/Night | Auto(ICR) / Color / B/W |
| BLC Mode | BLC / HLC / WDR(140dB)/ SSA |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D DNR |
| Motion Detetion | Off / On (4 Zone, Rectangle) |
| Region of Interest | Off / On (4 Zone) |
| Electronic Image Stabilization(EIS) | Support |
| Smart IR | Support |
| Defog | Support |
| Digital Zoom | 16x |
| Flip | 0°/90°/180°/270° |
| Mirror | Off / On |
| Privacy Masking | Off / On (4 Area, Rectangle) |
| Audio | |
| Compression | G.711a/G.711Mu/AAC/ G.726 |
| Network | |
| Ethernet | RJ-45 (100/1000Base-T) |
| Protocol | HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;
DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP; Bonjour;802.1x;Multicast;ICMP;IGMP;SNMP |
| Interoperability | ONVIF, PSIA, CGI |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 10 Users/20 Users |
| Edge Storage | NAS
Local PC for instant recording Mirco SD card 128GB |
| Web Viewer | IE, Chrome, Firefox, Safari |
| Management Software | Smart PSS, DSS, Easy4ip |
| Smart Phone | IOS, Android |
| Certifications | |
| Certifications | CE (EN 60950:2000)
UL:UL60950-1 FCC: FCC Part 15 Subpart B |
| Interface | |
| Video Interface | 1 Port(For adjustment only) |
| Audio Interface | 1/1 channel In/Out |
| RS485 | N/A |
| Alarm | 1 channel In: 5mA 5VDC
1 channel Out: 1A 30VDC / 0.5A 50VAC |
| Electrical | |
| Power Supply | DC12V,AC24V, PoE+ (802.3at)(Class 4) |
| Power Consumption | <18W |
| Environmental | |
| Operating Conditions | -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH |
| Strorage Conditions | -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH |
| Ingress Protection | IP67 |
| Vandal Resistance | IK10 |
| Construction | |
| Casing | Metal |
| Dimensions | Φ159.1mm×117.9mm(Φ6.26”×4.64”) |
| Net Weight | 0.96kg(2.12lb) |
| Gross Weight | 1.75 kg(3.56lb) |
